Replacement Battery For Bosch PowerPack 400 Frame - 36V 11.6Ah (417Wh) | Compatible With Active & Performance Line
Restore Your Range with Reliable Power. This 36V 11.6Ah (417Wh) lithium-ion battery is a direct replacement for the Bosch PowerPack 400 Frame Type. Built with high-quality 18650 power cells and a smart BMS, it ensures safety and longevity for your daily commute.
Compatibility: Bosch Active Line & Performance Line (Frame/Downtube Mount).
Capacity: 11.6Ah / 417Wh (Standard Long Range).
Safety First: Advanced BMS with Over-Current & Temperature Protection.
Durability: IP54 Splash-proof casing with durable mechanical structure.
Description
GEB-BOS-E36B 36V 11.6Ah (417.6Wh) Replacement Battery for Bosch
| Model Number | GEB-BOS-E36B |
| Application | Suitable for electric bicycle (Bosch Replacement System) |
| Nominal Voltage | 36V |
| Nominal Capacity | 11.6Ah |
| Total Energy | 417.6Wh |
| Cell Configuration | 10S 4P (Li-ion 18650 Power Cells) |
| Charge Current | Std: 2A | Fast: 4A | Max: 4.5A |
| Discharge Current | Cont.: 8A | Peak: 16A |
| Hardware Safety | Built-in 40A Fuse |
| Certifications | CE, WEEE (Recyclable) |
| Origin | Made in China |
High-Quality Replacement for Bosch E-Bike Systems
The GEB-BOS-E36B is a premium aftermarket Li-ion battery pack designed as a direct replacement for specific Bosch 36V e-bike systems. As clearly marked on the product label, it offers a reliable **36V output** with a capacity of **11.6Ah**, providing a total energy storage of **417.6Wh** for extended riding range.
Constructed with a durable black casing, this battery features a robust mounting bracket on the back for secure attachment to the bicycle frame. The side profile shows ergonomic grip ridges for easy handling and installation.
Engineered for Safety and Long Life
Safety is paramount. This battery pack carries the **CE mark**, indicating compliance with European safety standards. Beyond certifications, it is equipped with a sophisticated Battery Management System (BMS) and a physical **40A fuse** for redundant protection.
Key BMS Protection Parameters:
- Over-Charge Protection: 4.3V ±20mV per cell.
- Over-Discharge Protection: 2.4V ±100mV per cell.
- Over-Current Protection: 20A ±3A (with 1600ms delay for startup peaks).
- Short-Circuit Protection: Instantaneous response (120-240μs).
- Temperature Protection: Monitors both charging (cut-off at 45°C) and discharging (cut-off at 50°C).
Stable Performance Characteristics
This battery is designed for stability. It supports a standard discharge current of 5A, with a maximum continuous output of **8A** and the ability to handle short bursts up to **16A**. This performance profile is ideal for standard 250W e-bike motors, ensuring smooth power delivery without overstressing the cells.
For charging, it accepts a standard 2A current for maximum cycle life, but can also be fast-charged at up to 4A (max 4.5A input) using a compatible CC/CV charger with a 42V limit.
Reliable Manufacturing
Produced in China under strict quality control measures, the GEB-BOS-E36B is a testament to reliable manufacturing. Each pack is meticulously assembled using 10S4P 18650 power cells with consistent internal resistance (≤200mΩ), ensuring uniform performance and durability.
