36V Lithium-ion Floor Scrubber Battery (Industrial Pack)
Engineered specifically for demanding commercial cleaning machinery, walk-behind floor scrubbers, and industrial sweepers, the GEB 36V Lithium-Ion Floor Scrubber Battery Pack delivers reliable continuous power and exceptional peak current capability (up to 5C). Measuring 390 × 110 × 75 mm and weighing approximately 3.0kg, it serves as a lightweight, maintenance-free drop-in replacement for bulky lead-acid batteries, eliminating toxic acid fumes and shortening daily charging downtime to 2-3 hours.
Description
General Electronics Technology Co., Ltd. is one of the leading manufacturers and suppliers of 36V Lithium-ion Floor Scrubber Battery (Industrial Pack) in China. We are committed to providing high quality custom service and OEM&ODM service to global clients. Please feel free to wholesale durable lithium battery packs in stock here and get quotation from our factory.
Engineering Overview & Quick Assessment
This 36V industrial lithium battery pack is designed for commercial walk-behind and ride-on floor scrubbers with 1C normal and 5C peak discharge capability. Check machine battery tray dimensions (390 × 110 × 75 mm), operating current, connector model (Anderson), and 42.0V lithium charger requirements before replacement.
Verified Engineering Specifications
| Technical Parameter | Factory Benchmark & Tolerance Range |
|---|---|
| Nominal Voltage | 36.0V (Operating Range: 30.0V - 42.0V) |
| Chemistry & Type | Ternary Lithium-ion (Grade-A High-Discharge Cells) |
| Standard Discharge Rate | 1.0C Normal Continuous |
| Max Continuous Discharge | 5.0C High-Pulse Capability (Handles motor startup surge) |
| Standard Charging Current | ≤ 3.0A (Fast charge support up to 5.0A continuous) |
| Dimensions & Weight | 390 × 110 × 75 mm (±1.5mm) / Approx. 3.0 kg |
| Operating Temperatures | Charge: 0°C to 45°C | Discharge: -20°C to 60°C |
| Cycle Life Rating | Up to 1,000 Cycles (@ 80% DoD, residual capacity ≥ 80%) |
| Recommended Connectors | Anderson SB50 / Powerpole, M6 Terminal Lugs (Customizable) |
| Documentation & Compliance | CE, UN38.3, MSDS, RoHS, Marine DG Transport Report |
Motor & Drivetrain Compatibility
Compatible Motor Systems: Compatible with commercial walk-behind and ride-on floor scrubbers (Tennant, Nilfisk, Kärcher, Taski, IPC Eagle 36V conversion projects).
Pre-Installation Check: Confirm that your floor scrubber charger is set to lithium-ion profile (42.0V cutoff) rather than lead-acid desulfation mode.
Industrial Quality Architecture & Safety
- Automated Cell Sorting & Grading: Every cylindrical cell undergoes automated grading to ensure capacity variance ≤ 1.5% and internal resistance (IR) difference ≤ 2mΩ.
- Precision Pure Nickel Interconnects: Ultrasonic/spot-welded pure nickel strips lower internal resistance, minimize Joule heating during sustained hill-climbing, and prevent thermal runaway.
- Multi-Tier Smart BMS Protection: Real-time hardware monitoring protects against over-charge (4.25V/cell cut), over-discharge (2.8V/cell cut), continuous high-amperage over-current, and short-circuit faults with automatic reset.
- Shock-Resistant Structural Casing: Impact-resistant ABS+PC flame-retardant enclosure (UL94-V0 rated) shields the internal pack from trail debris, road vibration, and accidental drops.
OEM / ODM Customization & Sourcing Workflow
Shenzhen General Electronics Technology Co., Ltd. (GEB) provides complete end-to-end custom battery manufacturing for e-bike brands, distributors, and fleet operators:
Customizable BMS protocols (CAN-Bus, UART, RS485), customized wiring harnesses (Anderson, XT60, XT90-S, waterproof Julet connectors), and tailored discharge profiles.
Fully certified with UN38.3 test reports, MSDS, CE, RoHS, and Sea/Air Dangerous Goods (DG) freight classification for smooth customs clearance worldwide.
Frequently Asked Questions (FAQ)
Q1: How can I verify that this battery will fit my specific e-bike frame?
A: Download the 1:1 scale dimensional drawing or compare the exact enclosure length, width, and height listed in our specification table above with your frame triangle clearance. Ensure a minimum of 15-20mm clearance along the sliding direction for key release.
Q2: What is the sample lead time and mass-production turnaround?
A: Evaluation sample units typically ship within 5 to 7 business days. Mass production batches (100 to 1,000+ units) are fulfilled within 20 to 25 working days depending on cell supply allocation and custom BMS requirements.
Q3: Can GEB customize the battery housing color, branding, and connector pinouts?
A: Yes. We offer laser-etched OEM branding, silk-screened logos, custom color finishes for qualifying order volumes, and custom discharge/charge wiring pinouts tailored to your motor controller.
Hot Tags: 36v li-ion floor scrubber battery (industrial pack), 36v li-ion floor scrubber battery (industrial pack) manufacturer, custom lithium battery pack, OEM battery factory, Silver Fish Battery 36v
