Ebike Battery 48v 13ah

GEB E-Bike Battery 48V 13Ah - Reliable Replacement & Upgrade Power

Power up your ride with the dependable GEB 48V 13Ah Lithium-ion E-bike Battery. Specifically designed as a high-quality replacement or upgrade, this battery delivers consistent power and reliable range for your electric bicycle. Built with premium Brand Name 18650 NMC cells and protected by an advanced Battery Management System (BMS), it offers an excellent balance of performance, longevity, and safety. Ensure compatibility by selecting the correct BMS rating for your motor power.



Key Specifications:

Brand Name:	GEB
Model / Type:	Ebike Battery 48V 13Ah
Nominal Voltage:	48V (Other voltages may be available optionally)
Nominal Capacity:	13Ah (Other capacities may be available optionally)
Total Energy:	Approx. 624 Wh (Watt-hours)
Battery Management System (BMS):	Configurable Continuous Discharge Current: 13A to 30A IMPORTANT: Select BMS rating matching your motor power (Supports 250W up to 1000W motors). Please specify motor wattage when ordering.
BMS Protection Functions:	Over-Current Protection, Over-Discharge Protection, Over-Charge Protection, Short-Circuit Protection, Cell Balancing.
Approx. Dimensions (L*W*H):	430mm x 105mm x 43mm (Please verify case dimensions for fitment)
Discharge Cut-Off Voltage:	~37.7V
Max Charge Voltage:	54.6V
Expected Cycle Life:	Up to 800 cycles (retaining approx. 80% of original capacity)
Cell Chemistry / Format:	Lithium NMC (LiNiMnCoO2) / 18650 Cylindrical Cells
Cell Quality:	High-Quality Brand Name 18650 Cells
Application:	Electric Bicycles (E-bikes) - Replacement / Upgrade
Warranty:	12 Months
Approx. Weight:	~3.2KG (may vary slightly)
Charging Temperature Range:	0°C to 45°C (32°F to 113°F)
Discharging Temperature Range:	-20°C to 60°C (-4°F to 140°F)
Storage Temperature Range:	-10°C to 40°C (14°F to 104°F) (Recommended)



Reliable Power for Your E-Bike Journeys

Experience consistent and reliable performance with the GEB 48V 13Ah ebike battery. Offering approximately 624Wh of energy, it provides a solid range suitable for daily commutes, running errands, and enjoyable leisure rides. This lithium battery is an excellent choice for replacing an old battery or upgrading for dependable power.



Advanced BMS for Safety and Longevity

Ride with confidence knowing your battery is protected by an integrated Battery Management System (BMS). This intelligent system actively monitors and manages the battery, providing crucial safeguards against over-charging, over-discharging, over-current, and short circuits. It also includes cell balancing functions to help maximize battery lifespan and maintain performance over time.



Premium Cells for Lasting Performance

Constructed using high-quality, brand-name 18650 NMC (Nickel Manganese Cobalt) lithium-ion cells, this battery is built for endurance. NMC chemistry offers a great combination of energy density and power output. Expect a long service life with up to 800 charge cycles while retaining significant capacity, ensuring years of reliable use.



Crucial Compatibility Note: Match BMS to Your Motor

To ensure optimal performance, safety, and longevity for both the battery and your e-bike motor, it is essential to select the correct BMS continuous discharge current rating. This battery offers options from 13A to 30A, suitable for motors ranging from 250W to 1000W. **Please carefully check your motor's power requirements and specify your motor wattage when placing your order to receive the correctly configured BMS.** Using an incorrectly rated BMS can lead to underperformance or damage.





Frequently Asked Questions (FAQ)

Q: How far can I typically ride on a 48V 13Ah e-bike battery?
A: A 48V 13Ah battery (approx. 624Wh) generally provides a range of 25 to 40 miles (40 to 64 kilometers) on a single charge. However, the actual range varies significantly depending on factors such as: rider weight, terrain (hills/wind), pedal assist level used, motor efficiency, tire pressure, and battery age/condition.



Q: How does a 48V 15Ah battery compare in range to a 13Ah?
A: A 48V 15Ah battery has a higher capacity (720Wh vs 624Wh) than a 13Ah battery. All else being equal, you can expect a proportionally longer range, typically estimated around 30 to 50 miles (48 to 80 kilometers). The same influencing factors (terrain, weight, assist level, etc.) will affect the actual distance.



Q: What does "13AH" mean for a battery?
A: "AH" stands for Ampere-hour (or Amp-hour). It's a unit measuring electric charge capacity. A 13AH battery can theoretically deliver a current of 13 amps for one hour, or 1 amp for 13 hours, or any equivalent combination. Essentially, a higher Ah rating means the battery stores more energy and can potentially provide longer runtime (range).



Q: Can I use a battery with a higher Ah rating on my e-bike?
A: Yes, generally you can use a battery with a higher Amp-hour (Ah) rating than your original one, provided it meets these crucial conditions:

1. Voltage MUST Match: The new battery's nominal voltage (e.g., 48V) must be identical to your e-bike's system voltage (motor & controller).

2. Physical Fit: The new battery must physically fit into your bike's frame or mounting bracket.

3. Connector Compatibility: The discharge connector must match your bike's connector.

4. BMS Compatibility: Ensure the new battery's BMS can handle the current draw of your motor. (Our configurable BMS helps address this - remember to specify your motor power!).

Using a higher Ah battery will increase your e-bike's range but may also slightly increase weight.



Order Your GEB 48V 13Ah E-Bike Battery Today!

Ensure reliable power for your rides. Select the appropriate BMS configuration for your motor power and add this high-quality replacement battery to your cart. Contact us if you have any questions about compatibility or custom options.
